- nduction offers fast cooking and precise temperature control – Gas hob
- The best cooking performance at the highest energy efficiency
- The oven has two fans equipped with two circular heating elements allowing cooking with rotating heat
- New cooling system with tangential fan and airflow from the door to the splashback
- Internal halogen lighting on different levels guarantees excellent visibility
- Cooker top flushed with the working area thanks to adjustable feet
- Several cooking levels allow maximum flexibility of use
Type
Product Family:Cooker
Cooker size:90×60 cm
Hob type:Gas
Hob energy type:Gas
N. of ovens:1
Type of main oven:Gas with gas grill
EAN code:8017709325091
Installation positioning of the appliance:Free-standing, Class 1, Built-in, Class 2-1 norm UNI EN 30-1-1
Aesthetics
Colour:Stainless steel
Design:Standard
Finishing:Satin
Aesthetic:Classica
Command panel finish:Stainless steel
Series:Concerto
Material:Stainless steel
Upstand:Yes
Hob colour:Stainless steel
Type of pan stands:Cast Iron
Type of control setting hob:Control knobs
Control knobs:Smeg Classic
Controls colour:Stainless steel
No. of controls:8
Door:Full glass
Glass type:Black
Handle:Smeg Classic
Handle Colour:Brushed stainless steel
Storage compartment:Door
Feet:Stainless steel
Options Main Oven
End of cooking acoustic alarm:Yes
Minimum Temperature:80 °C
Maximum temperature:260 °C
Hob technical features
Total no. of cook zones:5
1st zone position:Front left
2nd zone position:Rear left
3rd zone position:Central
4th zone position:Rear right
5th zone position:Front right
1st zone type:Gas – Rapid
2nd zone type:Gas – Semi Rapid
3rd zone type:Gas – UR
4th zone type:Gas – Semi Rapid
5th zone type:Gas – AUX
1st zone power:2.90 kW
2nd zone power:1.75 kW
3rd zone power:4.00 kW
4th zone power:1.75 kW
5th zone power:1.00 kW
Type of gas burners:Standard
Burner caps:Matt black enamelled
Automatic electronic ignition:Yes
Gas safety valves:Yes
Main Oven Technical Features
Net volume of the cavity:105 l
Gross volume, 1st cavity:129 l
Cavity material:Ever Clean enamel
No. of shelves:5
Type of shelves:Metal racks
No. of lights:2
Light type:Halogen
Light Power:40 W
Fan number:2
Cooking time setting:Contaminuti fine cottura
Door opening:Flap down
Removable door:Yes
Full glass inner door:Yes
Total no. of door glasses:2
No.of thermo-reflective door glasses:1
Cooling system:Tangential
Grill type:Gas
Temperature control:Mechanical
Performance / Energy Label
Energy efficiency class:A
Energy consumption in conventional mode:7.93 MJ
Energy consumption per cycle in conventional mode:2.20 KWh
Electrical Connection
Electrical connection rating:120 W
Current:1 A
Voltage:220-240 V
Frequency:50/60 Hz
Power supply cable length:115 cm
Installed electric cable:Yes, Single phase
Gas Connection
Gas connection rating (W):15600 W
Gas Type:G30 LPG Liquid gas
Logistic Information
Dimensions of the product HxWxD (mm):900x900x600 mm
Width (mm):900 mm
Product Height (mm):900 mm
Depth (mm):600 mm
Dimensions of the packed product (mm):860X960X670 mm
Gross weight (kg):77.900 kg
Net weight (kg):69.000 kg
Packed width:960 mm
Packaged depth:670 mm
Height (mm) packed:860 mm
Maximum stackability:5
Type of packaging:Shrinkwrap
Packaging composition – paper & cardboard (kg):4.112 kg
Packaging composition – polystyrene (kg):1.315 kg
Packaging composition – wood (kg):2.660 kg
Packaging composition – plastic (kg):0.844 kg
Accessories Included
Other gas nozzles included:G20 Natural gas
Accessories included for Main Oven & Hob
Cast iron wok support:1
Moka stand:1
Rack with back and side stop:1
Grill mesh:1
40mm deep tray:1
